A 2004 segmentation algorithm as a graph pooling layer

Classical pooling downsamples on a fixed grid: a 2x2 max or average, applied everywhere, whether or not the four pixels underneath it have anything to do with each other. Post 69 reimplemented Felzenszwalb and Huttenlocher’s 2004 graph-based image segmentation from the paper and showed it is fast enough to run on a camera feed: sort every edge in a pixel graph by weight, walk the sorted list once, join two components whenever the edge between them is cheap relative to how varied each component already is. I am not reimplementing that here, and I am not re-deriving it either, felzenszwalb.rs’s merge rule (post 69’s file, untouched by this post) is reused exactly as it stands. What I did with it, in the masters research this post is drawn from, was put it to a different job: instead of segmenting a photograph, it coarsens a graph of feature vectors, which is what a pooling layer in a neural network needs to do. The merge rule does not change either way. What changes is the one number every merge decision depends on: the distance between two nodes.

The same merge rule, a different distance

Felzenszwalb and Huttenlocher’s threshold rule, exactly as post 69 derives it, merges two components $C_u$ and $C_v$ across an edge of weight $w$ when

$$w \le \tau(C_u) \quad \text{and} \quad w \le \tau(C_v), \qquad \tau(C) = \frac{k}{|C|}$$

Nothing about that rule cares what $w$ is measuring. Post 69’s felzenszwalb.rs sets $w$ to the Euclidean distance between two pixels’ RGB values, because that is what Felzenszwalb and Huttenlocher’s paper does for a photograph. PegbisPooling, the class I built around a vendored copy of the same algorithm, sets $w$ to a learned distance between two nodes’ feature vectors instead:

def forward(self, x, pos, edge_index, batch):
    e = (x[edge_index[0]] - x[edge_index[1]])**2
    e = torch.sqrt(e.matmul(self.weight.abs()/self.weight.abs().sum())+1e-10).view(-1)

x is the graph’s node features, one row per node; self.weight is one learnable scalar per feature channel. I sat down to write this post half remembering that as a softmax over the channel weights, the way an attention weighting usually gets normalised. Rereading the actual line, it is not: self.weight.abs()/self.weight.abs().sum() is plain L1 normalisation of the absolute value, no exponential in sight. It has the property that matters for this post either way, every channel’s contribution stays non-negative and the whole vector sums to one, so e is still a legitimate distance, just one whose per-channel scaling gradient descent gets to set rather than a fixed 1 for every colour channel and 0 for everything else. The widget below lets you set that vector by hand instead of training it, which is the honest thing a reader can actually do with it.

That e, one score per edge, is the entire interface between “a distance a network learned” and Felzenszwalb & Huttenlocher’s algorithm. Everything downstream of it, sorting, the union-find, the per-component threshold, is segment_graph’s job (the vendored, torch-tensor-flavoured port I did not write and do not reproduce here, see the credit below), which is the exact same job felzenszwalb.rs::segment_graph_into does for post 69. The merge predicate does not know or care that e came from a learned weight instead of sqrt((r1-r2)^2 + (g1-g2)^2 + (b1-b2)^2).

What the layer actually pools

A pooling layer has to do more than decide which nodes merge, it has to produce a smaller graph the next layer can run on. __merge_edges__ does that part:

def __merge_edges__(self, x, pos, edge_index, batch, edge_score):
    cluster = segment_graph(edge_index.cpu(), edge_score.cpu(), x.size(0), self.cluster_c, self.min_size).to(x.device)
    new_x = scatter_mean(x, cluster, dim=0)
    new_pos = scatter_mean(pos, cluster, dim=0)
    new_batch = x.new_empty(new_x.size(0), dtype=torch.long)
    new_batch = new_batch.scatter_(0, cluster, batch)
    new_edge_index = knn_graph(new_pos, self.k, new_batch, loop=False, flow=self.flow)

cluster is Felzenszwalb & Huttenlocher’s output, a component id per node. scatter_mean folds every merged group’s features and positions down to one row each, the pooled node’s feature is the mean of everything that merged into it, its position is the mean position too. A fresh k-nearest-neighbour graph gets rebuilt over the coarse node positions, because the layer’s input was a point cloud with no fixed grid to fall back to, knn_graph is doing the job the widget’s own coarse-graph panel does more directly below, by drawing an edge between two pooled regions whenever the original graph had an edge crossing between them.

There are two dated versions of this file in the repository, pegbis_pooling_2020_02_12_0.py and pegbis_pooling_2020_03_07_00_diff_loss.py (this post’s date is the second file’s own filename, landed in git on 2020-04-11 in one bulk import commit together with the first thirteen of my own experiment scripts, so the filename date is what I am trusting, not the commit date). The February version merges with one symmetric threshold, self.c. The March version, quoted above, splits that into cluster_c (the merge threshold itself, unchanged in meaning) plus ca, cb, alpha, beta, and adds a training signal for the edge weight itself:

def lossfn(self, cluster, y, edge_score, edge_index):
    val_inst = y >= 0
    same_class_mask = (y[edge_index[0]] == y[edge_index[1]]) * val_inst[edge_index[0]] * val_inst[edge_index[1]]
    yi_eq_yj = edge_score[same_class_mask]
    yi_neq_yj = edge_score[torch.logical_not(same_class_mask)]
    topk = min(len(yi_eq_yj), len(yi_neq_yj), self.loss_top_k)
    return self.alpha*(yi_eq_yj.topk(topk, largest=True)[0] - self.ca).clamp(0).mean() + \
        self.beta*(self.cb - yi_neq_yj.topk(topk, largest=False)[0]).clamp(0).mean()

yi_eq_yj is the learned distance on edges whose two endpoints carry the same ground-truth label, yi_neq_yj the same on edges that cross a class boundary. The loss pushes the worst same-class edges below ca and the worst different-class edges above cb, an auxiliary signal aimed squarely at the one thing this post is about: shaping what “close” means before Felzenszwalb & Huttenlocher’s threshold ever sees an edge weight.

Wired in more than I remembered

That does not change the honest bottom line: no checkpoint, log, or accuracy number survives for any of those seven scripts either, so I still cannot tell you whether it worked. It does change the shape of the story. This was not a layer I wrote once and set aside untested, it got a real three weeks of hand-tuned attention, stacked three deep in a real model, before the graph U-Net that eventually did get trained end to end (dgUnetEP.py, the subject of post 63) settled on a plainer, purely distance-based PosEdgePool instead. An idea that got tried, more than once, and was quietly dropped for something simpler, rather than one that never left the drawing board.

Trying it on an image, since I have no point cloud to show you

Every cell of a small grid over the image (default 24 cells on the long side) gets a 4-channel feature vector: red, green, blue, and a texture channel, the magnitude of a small Sobel gradient of luminance over the same grid. That grid is a graph, same 8-connected neighbours felzenszwalb.rs uses for pixels. Both panels pool it through the exact same PegbisPooling formula, sqrt(sum((fi-fj)^2 . |weight| / sum|weight|)), computed by the one edge_weight function in graphpool.rs. The “fixed colour distance” panel’s weight is pinned at equal red, green, blue and zero texture the moment its handle is created and never moves again, which is what recovers the classic, unweighted-feeling Felzenszwalb & Huttenlocher metric post 69 already uses on full photographs as a special case rather than a second implementation of it. The “shape the metric” panel’s weight is whatever its four sliders currently say. Pushing all the weight onto texture and away from colour makes the merge rule blind to a sky-and-mountain colour difference and sensitive only to how smooth or detailed a patch is; pushing it back onto equal red, green and blue with texture at zero makes the two panels’ edge weights identical, not just similar, because at that point they are the same function fed the same weight vector. Nothing about the merge rule changes between the two panels either way, graphpool.rs calls felzenszwalb.rs::segment_graph_into in both, only the weight vector its edge-weight function reads does.

Below the merge threshold and weight sliders sits a “reveal merges” slider. It does not re-run a separate incremental version of the algorithm, segment_graph_into already sorts its edges and only ever looks at ones already processed, so replaying it on a shorter prefix of the very same sorted list gives back exactly the labels a full pass would have had at that point. Scrubbing it back shows the grid as a lot of small, barely-merged regions; scrubbing forward shows them coalescing exactly the way the sorted-edges, one-pass argument post 69 makes says they must.

Each panel also draws its own pooled graph next to the original grid, not just a recoloured image: one node per surviving region, placed at that region’s mean position, sized by how many cells merged into it, connected to whichever other regions it still shares a boundary with. That is scatter_mean and the coarse adjacency __merge_edges__ builds with knn_graph, done directly from the grid’s own edges since there is no point cloud here to re-run a k-NN search over. A third panel pools the same starting grid the way an ordinary CNN would, fixed square blocks, no notion of which cells actually belong together, sized so its block count lands close to the graph panels’ own region counts. Same input, same rough output size, one of them shaped by what is actually in the image.

With JavaScript on, this becomes a live widget: a small feature grid over this photo (or your own upload) gets pooled two ways, fixed colour distance and a weight you can shape across red, green, blue and texture, with a merge-reveal slider and each panel’s pooled graph drawn beside its starting grid. A third panel pools the same grid on a fixed block, for comparison.

The Rust side

graphpool.rs is a new module in segment-wasm, the same crate post 69’s felzenszwalb.rs lives in, unionfind.rs (posts 35, 42) and felzenszwalb.rs itself are untouched. It reuses felzenszwalb::segment_graph_into for every merge, both the full pass and the “reveal merges” prefix replay, and adds exactly what post 69’s module did not need: a multi-channel weighted edge builder, the scatter_mean pooling, and the coarse adjacency. Ten new tests exercise it, including one that checks the actual claim this post makes: with the same threshold k, the same pair of nodes merges when the weight favours their (small) colour difference and stays apart when it favours their (large) texture difference, on a real computed edge weight rather than an assertion in prose. cargo test -p segment-wasm is 52 cases across the whole crate now, 10 of them new here, all passing. The compiled module grew from about 137.9 kB to 147.1 kB, roughly 9 kB for this module.

Where this leaves it

No accuracy number exists for PegbisPooling anywhere I can find, on ScanNet or on anything else. What does exist is a working, tested reuse of a 2004 algorithm as a learned-metric pooling operator, three weeks of real (if never validated) training attempts at it, and, in the graph U-Net that did eventually get trained end to end, a decision to use something plainer instead. That last part is not a failure this post is smoothing over, PosEdgePool’s job in post 63 is the same merge-and-coarsen job this layer does, just without the learned metric, which is itself evidence the metric-shaping idea was interesting enough to try and not, in the end, the piece that made it into the architecture that got finished.
